Главная Каталог продукции Toolunited 16 202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth 16ER11,5NPTF LWN20T

16ER11,5NPTF LWN20T

Артикул: 16ER11,5NPTF LWN20T

В наличии

В корзину

Описание

Характеристики

COMPC Company code

BK - Boehlerit

Delivery state valid from

1/10/2016

DIN

BK-GS16ER

FamilyProducts

Indexable Insert - External Thread, NPTF

GRDMFG Grade manufacturers designation

LWN20T

GRDPRIO Standard designation of the grade main application

HC-N20

IC Inscribed circle diameter

9.52 mm

IH Insert hand

R - Right

INSL Insert length

16 mm

Interface codes

J6 /

ISYC Subclass

202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

BK-GS16ER

Name Identifying order number

16ER11,5NPTF LWN20T

NOF Flute count

NT Tooth count

PDX Profile distance X

1 mm

PDY Profile distance Y

0.8 mm

PFS Profile form

S1 Insert thickness total

3.4 mm

STDDES Standard designation

16ER11,5NPTF

THFT Thread form type

NPTF

TPIN Threads per inch minimum

TPT Thread profile type

V - Full profile

TTP Thread type

A - External thread

Working process

DGA - Thread turning, external
