Главная Каталог продукции Toolunited 16 202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth 16ELAG55 LWN20T

16ELAG55 LWN20T

Артикул: 16ELAG55 LWN20T

В наличии

В корзину

Описание

Характеристики

COMPC Company code

BK - Boehlerit

Delivery state valid from

1/10/2016

DIN

BK-GS16EL

FamilyProducts

Indexable Insert - External Thread, Profile 55°

GRDMFG Grade manufacturers designation

LWN20T

GRDPRIO Standard designation of the grade main application

HC-N20

IC Inscribed circle diameter

9.52 mm

IH Insert hand

L - Left

INSL Insert length

16 mm

Interface codes

J6 /

ISYC Subclass

202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

BK-GS16EL

Name Identifying order number

16ELAG55 LWN20T

NOF Flute count

NT Tooth count

PDX Profile distance X

1.7 mm

PDY Profile distance Y

1.2 mm

PFS Profile form

RETL Flank radius left hand

0.07 mm

RETR Flank radius right hand

0.07 mm

S1 Insert thickness total

3.4 mm

STDDES Standard designation

16ELAG55

THFT Thread form type

55°

TPIN Threads per inch minimum

TPIX Threads per inch maximum

TPN Thread pitch minimum

0.5 mm

TPT Thread profile type

T - Partial profile

TPX Thread pitch maximum

3 mm

TTP Thread type

A - External thread

Working process

DGA - Thread turning, external
