08IL 16 UN IC228
08IL 16 UN IC228
Артикул:
5903343
В наличии
Характеристики
CB Chip breaker face count
0 - Without chip breaker
COMPC Company code
IS - Iscar
Delivery state valid from
12/1/2014
DIN
IS-08IL
FamilyProducts
08IL 16 UN IC228
GRDMFG Grade manufacturers designation
IC228
IC Inscribed circle diameter
4.76 mm
ID Technical product number
5903343
IH Insert hand
L - Left
INSL Insert length
8 mm
Interface codes
J6 /
ISYC Subclass
202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
IS-08IL
Name Identifying order number
08IL 16 UN IC228
NOF Flute count
3
NT Tooth count
1
PDPT Profile depth insert
0.6 mm
PFS Profile form
6
REL Corner radius left hand
0.09 mm
RER Corner radius right hand
0.09 mm
STDDES Standard designation
08IL 16 UN
THFT Thread form type
UN
TPIN Threads per inch minimum
16
TPIX Threads per inch maximum
16
TPN Thread pitch minimum
0.7 mm
TTP Thread type
I - Internal thread
Working process
DGI - Thread turning, internal
