Главная Каталог продукции Toolunited 16 201-04 - Rectangular insert LQMU110704PNER-MJ AH725

LQMU110704PNER-MJ AH725

Артикул: 6861478

В наличии

В корзину

Описание

Характеристики

AS Clearance angle wiper edge

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

TiAlN-PVD

COMPC Company code

TT - Tungaloy

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

10/26/2012

DIN

LQ1107PN3R

EPSR Insert included angle

90 Degree

FamilyProducts

Wendeschneidplatte zum Fräsen LQMU-MJ

GRD2ND Standard designation of the grade 2nd application

HC-P40

GRD3RD Standard designation of the grade 3rd application

HC-K25

GRDMFG Grade manufacturers designation

AH725

GRDPRIO Standard designation of the grade main application

HC-P30

IC Inscribed circle diameter

9 mm

ID Technical product number

6861478

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-04 - Rectangular insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

11 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

LQ1107PN3R

Materials

P,K,S

Name Identifying order number

LQMU110704PNER-MJ AH725

RE Corner radius

0.4 mm

S Insert thickness

8.3 mm

S1 Insert thickness total

8.3 mm

STDDES Standard designation

LQMU110704PNER

TCINS Tolerance class insert

W1 Insert width

9 mm

Working process

DDA - External turning,DDI - Internal turning
