Главная Каталог продукции Toolunited 16 201-05 - Parallelogram-shaped insert APKT1604PDTR AC325

APKT1604PDTR AC325

Артикул: APKT1604PDTR AC325

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

ANN Clearance angle minor

11 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CECC Cutting edge condition code

T - Chamfered

COATN Coating / Покрытие

TiCN+TiN

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

Delivery state valid from

12/31/2020

DIN

AP1604 3R

EPSR Insert included angle

85 Degree

FamilyProducts

Sumitomo indexable insert for milling

GRD2ND Standard designation of the grade 2nd application

HC-P30

GRD3RD Standard designation of the grade 3rd application

HC-M30

GRDMFG Grade manufacturers designation

AC325

GRDPRIO Standard designation of the grade main application

HC-P20

IC Inscribed circle diameter

9.525 mm

ID Technical product number

APKT1604PDTR AC325

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

16 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

AP1604 3R

M M-dimension

0.013 mm

Name Identifying order number

APKT1604PDTR AC325

RE Corner radius

0.8 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

APKT1604PDTR

TCINS Tolerance class insert

K - Cold formed

W1 Insert width

9.525 mm

Working process

No working processes available
