Главная Каталог продукции Toolunited 16 201-05 - Parallelogram-shaped insert APET103504PDER-F ACZ310

APET103504PDER-F ACZ310

Артикул: APET103504PDER-F ACZ310

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

AS Clearance angle wiper edge

15 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

ZX-TiNAlN

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

2/24/2021

DIN

AP1035PD3R

EPSR Insert included angle

85 Degree

FamilyProducts

insert for milling, WEM/WMM/WRM series endmills

GRD2ND Standard designation of the grade 2nd application

HC-K10

GRD3RD Standard designation of the grade 3rd application

HC-P20

GRDMFG Grade manufacturers designation

ACZ310

GRDPRIO Standard designation of the grade main application

HC-P10

IC Inscribed circle diameter

6.35 mm

ID Technical product number

APET103504PDER-F ACZ310

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

10 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

AP1035PD3R

Materials

Name Identifying order number

APET103504PDER-F ACZ310

RE Corner radius

0.4 mm

S Insert thickness

3.5 mm

S1 Insert thickness total

3.5 mm

STDDES Standard designation

APET103504

TCINS Tolerance class insert

W1 Insert width

6.35 mm

Working process

No working processes available
