ADGT120416R-D67 WKP35S
ADGT120416R-D67 WKP35S
Артикул:
5885981
В наличии
Характеристики
BS Wiper edge length
1 mm
CBMD Chip breaker manufacturers designation
D67
CECC Cutting edge condition code
E - Rounded
COATN Coating
TiCN+Al2O3+(TiCN)
COMPC Company code
W - Walter
CSP Coolant supply property
0 - Without coolant supply
D1 Fixing hole diameter
3.4 mm
Delivery state valid from
12/1/2023
DIN
W-AD1204163RB$$16
EPSR Insert included angle
85 Degree
FamilyProducts
Positive rhombic ADGT
GRDMFG Grade manufacturers designation
WKP35S
IC Inscribed circle diameter
8.4 mm
ID Technical product number
5885981
IFS Insert mounting style code
3 - Counter bore for screws with taper angle from 40° to 60°
IH Insert hand
R - Right
Interface codes
J6 / J441
ISISO ISO property
0
ISO
WR$$AD1204163RB$$16
ISYC Subclass
201-05 - Parallelogram-shaped insert
L Cutting edge length
13.6 mm
LE Cutting edge effective length
12 mm
LOC-03 ISO
WR$$AD1204163RB$$16
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
W-AD1204163RB$$16
Name Identifying order number
ADGT120416R-D67 WKP35S
NOI Insert index count
2
RE Corner radius
1.6 mm
S Insert thickness
4.76 mm
S1 Insert thickness total
4.76 mm
STDDES Standard designation
ADGT120416R
TCE Tipped cutting edge code
S
TCINS Tolerance class insert
G
W1 Insert width
8.4 mm
Working process
FPL - Face milling
WT Weight of item
0.004 kg
