OEMX1705EER1-JS F7010

Артикул: OEMX1705EER1-JS F7010

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

20 Degree

AS Clearance angle wiper edge

20 Degree

BS Wiper edge length

1.4 mm

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

TiN-Al2O3

COMPC Company code

MI - Mitsubishi Materials

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

4/1/2022

DIN

MI-OEMX1705

EPSR Insert included angle

135 Degree

FamilyProducts

INSERT, MILLING, COATED

GRD2ND Standard designation of the grade 2nd application

HC-M10-M20

GRDMFG Grade manufacturers designation

F7010

GRDPRIO Standard designation of the grade main application

HC-P10-P20

IC Inscribed circle diameter

17 mm

IFS Insert mounting style code

7 - Prismatic clamping, concave

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-09 - Octogonal insert

KRINS Cutting edge angle major

75 Degree

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

MI-OEMX1705

Materials

P,M

Name Identifying order number

OEMX1705EER1-JS F7010

RE Corner radius

1 mm

S Insert thickness

5 mm

S1 Insert thickness total

5 mm

STDDES Standard designation

OEMX1705EER

TCINS Tolerance class insert

Working process

F - Milling,FPL - Face milling,FZI - Circular milling
