Главная Каталог продукции Toolunited 16 201-00 - Regular Insert unspecified SEET13T3AGFN-JP HTi10

SEET13T3AGFN-JP HTi10

Артикул: SEET13T3AGFN-JP HTi10

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

20 Degree

AS Clearance angle wiper edge

30 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

COMPC Company code

MI - Mitsubishi Materials

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.3 mm

Delivery state valid from

4/1/2022

DIN

SE13T3AG3N

EPSR Insert included angle

45 Degree

FamilyProducts

INSERT, MILLING, UNCOATED

GRDMFG Grade manufacturers designation

HTi10

GRDPRIO Standard designation of the grade main application

HW-K10

IC Inscribed circle diameter

13.4 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-00 - Regular Insert unspecified

KRINS Cutting edge angle major

45 Degree

L Cutting edge length

13.4 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SE13T3AG3N

Materials

Name Identifying order number

SEET13T3AGFN-JP HTi10

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

STDDES Standard designation

SEET13T3AGFN-JP

TCINS Tolerance class insert

Working process

F - Milling,FEC - Square shoulder milling,FPL - Face milling,FPR - Profile milling,FZI - Circular milling
