HCD D205-090-QF IC908

Артикул: 5604252

В наличии

В корзину

Описание

Характеристики

CECC Cutting edge condition code

T - Chamfered

COATN Coating / Покрытие

TiAlN

COMPC Company code

IS - Iscar

DIN

IS-57806626211639

EPSR Insert included angle

45 Degree

FamilyProducts

90° V-Shaped Inserts with 2 Cutting Edges for Chamfering, Countersinking and Spot Drilling

GRDMFG Grade manufacturers designation

IC908

ID Technical product number

5604252

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

R - Right

Interface codes

J6 / J441

ISISO ISO property

ISO

IS$$57806626211639

ISYC Subclass

201-00 - Regular Insert unspecified

KRINS Cutting edge angle major

45 Degree

L Cutting edge length

15.5 mm

LOC-03 ISO

IS$$57806626211639

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

IS-57806626211639

Name Identifying order number

HCD D205-090-QF IC908

S Insert thickness

4.65 mm

Working process

No working processes available

WT Weight of item

0.02 kg
