Главная Каталог продукции Toolunited 16 201-07 - Trigon insert WPMT090725ZPL-ML AH120

WPMT090725ZPL-ML AH120

Артикул: 6853063

В наличии

В корзину

Описание

Характеристики

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

COATN Coating / Покрытие

TiAlN-PVD

COMPC Company code

TT - Tungaloy

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5.5 mm

Delivery state valid from

9/27/2007

DIN

WP0907ZP3N

FamilyProducts

indexable insert for high feed holder

GRD2ND Standard designation of the grade 2nd application

HC-P40

GRD3RD Standard designation of the grade 3rd application

HC-K25

GRDMFG Grade manufacturers designation

AH120

GRDPRIO Standard designation of the grade main application

HC-P30

ID Technical product number

6853063

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

WP0907ZP3N

Name Identifying order number

WPMT090725ZPL-ML AH120

RE Corner radius

2.5 mm

STDDES Standard designation

WPMT0907ZP3L

TCINS Tolerance class insert

Working process

DDA - External turning,DDI - Internal turning
