WNMX 080712-M4PW IC8150

Артикул: 5508504

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CBMD Chip breaker manufacturers designation

M4PW

COATN Coating / Покрытие

CVD

COMPC Company code

IS - Iscar

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

8/17/2015

DIN

WN0807122N

EPSR Insert included angle

80 Degree

FamilyProducts

Double-Sided Trigon Inserts

GRD2ND Standard designation of the grade 2nd application

HC-P01

GRD3RD Standard designation of the grade 3rd application

HC-K15

GRDMFG Grade manufacturers designation

IC8150

GRDPRIO Standard designation of the grade main application

HC-P35

IC Inscribed circle diameter

12.7 mm

ID Technical product number

5508504

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

L Cutting edge length

8.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

WN0807122N

Materials

Name Identifying order number

WNMX 080712-M4PW IC8150

RE Corner radius

1.2 mm

S Insert thickness

6.78 mm

S1 Insert thickness total

6.78 mm

STDDES Standard designation

WNMX080712

STDDESAnsi Standard designation ANSI

WNMX453

TCINS Tolerance class insert

Working process

DDA - External turning
