Главная Каталог продукции Toolunited 16 201-07 - Trigon insert WNMG432 ENZ AC420K

WNMG432 ENZ AC420K

Артикул: WNMG432 ENZ AC420K

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

COATN Coating / Покрытие

Super FF

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5.16 mm

Delivery state valid from

10/26/2011

DIN

WN0804082N

EPSR Insert included angle

80 Degree

FamilyProducts

negative insert for turning, WNMG-NUZ

GRDMFG Grade manufacturers designation

AC420K

GRDPRIO Standard designation of the grade main application

HC-K20

IC Inscribed circle diameter

12.7 mm

ID Technical product number

WNMG432 ENZ AC420K

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

WN0804082N

Materials

Name Identifying order number

WNMG432 ENZ AC420K

RE Corner radius

0.8 mm

S Insert thickness

4.762 mm

S1 Insert thickness total

4.762 mm

STDDES Standard designation

WNMG080408

STDDESAnsi Standard designation ANSI

WNMG432

TCINS Tolerance class insert

Working process

No working processes available
