Главная Каталог продукции Toolunited 16 201-07 - Trigon insert WNMG060404-CB NS530

WNMG060404-CB NS530

Артикул: WNMG060404-CB NS530

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

COMPC Company code

TT - Tungaloy

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

3.81 mm

Delivery state valid from

9/27/2012

DIN

WN0604 2N

EPSR Insert included angle

80 Degree

FamilyProducts

insert for turning WNMG, CB breaker

GRDMFG Grade manufacturers designation

NS530

GRDPRIO Standard designation of the grade main application

HT-P15

IC Inscribed circle diameter

9.525 mm

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

L Cutting edge length

6.5 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

WN0604 2N

Materials

P,M

Name Identifying order number

WNMG060404-CB NS530

RE Corner radius

0.4 mm

STDDES Standard designation

WNMG060404

STDDESAnsi Standard designation ANSI

WNMG331

TCINS Tolerance class insert

Working process

DDA - External turning
