Главная Каталог продукции Toolunited 16 201-01 - Triangle insert TPMN222 AC410K

TPMN222 AC410K

Артикул: TPMN222 AC410K

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CB Chip breaker face count

0 - Without chip breaker

COATN Coating / Покрытие

Super FF

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

10/26/2011

DIN

TP1103 1N

EPSR Insert included angle

60 Degree

FamilyProducts

insert for turning TPMN

GRDMFG Grade manufacturers designation

AC410K

GRDPRIO Standard designation of the grade main application

HC-K10

IC Inscribed circle diameter

6.35 mm

ID Technical product number

TPMN222 AC410K

IFS Insert mounting style code

1 - Without bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-01 - Triangle insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

TP1103 1N

Name Identifying order number

TPMN222 AC410K

RE Corner radius

0.8 mm

S Insert thickness

3.175 mm

S1 Insert thickness total

3.175 mm

STDDES Standard designation

TPMN110308

STDDESAnsi Standard designation ANSI

TPMN222

TCINS Tolerance class insert

Working process

No working processes available
