TNMG160404L-1M NX3035

Артикул: TNMG160404L-1M NX3035

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

BN Face land width

0.2 mm

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

L-1M

CECC Cutting edge condition code

T - Chamfered

COMPC Company code

MI - Mitsubishi Materials

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

3.81 mm

Delivery state valid from

4/1/2022

DIN

TN1604042L

EPSR Insert included angle

60 Degree

FamilyProducts

insert for turning TNMG-L-1M

GAN Insert rake angle

15 Degree

GB Face land angle

0 Degree

GRD2ND Standard designation of the grade 2nd application

CT-P20

GRD3RD Standard designation of the grade 3rd application

CT-P30

GRDMFG Grade manufacturers designation

NX3035

GRDPRIO Standard designation of the grade main application

CT-P10

IC Inscribed circle diameter

9.525 mm

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

L - Left

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-01 - Triangle insert

L Cutting edge length

16.49 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

TN1604042L

Name Identifying order number

TNMG160404L-1M NX3035

RE Corner radius

0.4 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

TNMG160404L

STDDESAnsi Standard designation ANSI

TNMG331L

TCINS Tolerance class insert

Working process

DDA - External turning,DDB - External and internal turning,DDI - Internal turning,DFA - External form turning
