TNGG160404L-P TH10

Артикул: TNGG160404L-P TH10

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

COMPC Company code

TT - Tungaloy

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

3.81 mm

Delivery state valid from

8/24/2006

DIN

TN1604 2L

EPSR Insert included angle

60 Degree

FamilyProducts

Basic insert (negative) , -P chipbreaker

GAN Insert rake angle

0 Degree

GRDMFG Grade manufacturers designation

TH10

GRDPRIO Standard designation of the grade main application

HW-K10

IC Inscribed circle diameter

9.525 mm

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

L - Left

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-01 - Triangle insert

L Cutting edge length

16.5 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

TN1604 2L

Name Identifying order number

TNGG160404L-P TH10

NameAnsi Identifying order number inch alternative

TNGG 331 L-P TH10

RE Corner radius

0.4 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

TNGG160404L

STDDESAnsi Standard designation ANSI

TNGG331L

TCINS Tolerance class insert

Working process

DDA - External turning
