TNGG160402R-P GH110

Артикул: TNGG160402R-P GH110

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

COATN Coating / Покрытие

PVD

COMPC Company code

TT - Tungaloy

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

3.81 mm

Delivery state valid from

8/1/2012

DIN

TN1604 2R

EPSR Insert included angle

60 Degree

FamilyProducts

Basic insert (negative) , -P chipbreaker

GAN Insert rake angle

0 Degree

GRDMFG Grade manufacturers designation

GH110

IC Inscribed circle diameter

9.525 mm

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-01 - Triangle insert

L Cutting edge length

16.5 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

TN1604 2R

Name Identifying order number

TNGG160402R-P GH110

NameAnsi Identifying order number inch alternative

TNGG 330.5 R-P GH110

RE Corner radius

0.2 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

TNGG160402

TCINS Tolerance class insert

Working process

DDA - External turning
