Главная Каталог продукции Toolunited 16 201-01 - Triangle insert TEKN160308TR T130Z

TEKN160308TR T130Z

Артикул: TEKN160308TR T130Z

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

20 Degree

CB Chip breaker face count

0 - Without chip breaker

CECC Cutting edge condition code

T - Chamfered

COATN Coating / Покрытие

TiN

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

1/16/2007

DIN

TE1603 1R

EPSR Insert included angle

60 Degree

FamilyProducts

Sumitomo indexable insert for milling

GRD2ND Standard designation of the grade 2nd application

HC-P10

GRD3RD Standard designation of the grade 3rd application

HC-P25

GRDMFG Grade manufacturers designation

T130Z

GRDPRIO Standard designation of the grade main application

HC-P20

IC Inscribed circle diameter

9.525 mm

ID Technical product number

TEKN160308TR T130Z

IFS Insert mounting style code

1 - Without bore

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-01 - Triangle insert

L Cutting edge length

16.5 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

TE1603 1R

M M-dimension

0.013 mm

Name Identifying order number

TEKN160308TR T130Z

RE Corner radius

0.8 mm

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

TEKN160308TR

STDDESAnsi Standard designation ANSI

TEKN322TR

TCINS Tolerance class insert

K - Cold formed

Working process

No working processes available
