Главная Каталог продукции Toolunited 16 201-01 - Triangle insert Q-TPGM160304 BX360

Q-TPGM160304 BX360

Артикул: Q-TPGM160304 BX360

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

COMPC Company code

TT - Tungaloy

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

8/24/2006

DIN

TP1603 2N

EPSR Insert included angle

60 Degree

FamilyProducts

indexable insert, single cutting edge, positive

GRDMFG Grade manufacturers designation

BX360

GRDPRIO Standard designation of the grade main application

BN-P01

IC Inscribed circle diameter

9.525 mm

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-01 - Triangle insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

TP1603 2N

Name Identifying order number

Q-TPGM160304 BX360

RE Corner radius

0.4 mm

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

TPGM160304

STDDESAnsi Standard designation ANSI

TPGM321

TCINS Tolerance class insert

Working process

No working processes available
