Главная Каталог продукции Toolunited 16 201-02 - Square insert SPUN120308 TN5120

SPUN120308 TN5120

Артикул: 121315614

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CB Chip breaker face count

0 - Without chip breaker

COMPC Company code

WI - Widia

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

6/16/2013

DIN

SP1203081N

EPSR Insert included angle

90 Degree

FamilyProducts

indexable insert SP, single sided

GRDMFG Grade manufacturers designation

TN5120

IC Inscribed circle diameter

12.7 mm

ID Technical product number

121315614

IFS Insert mounting style code

1 - Without bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

12.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SP1203081N

Materials

Name Identifying order number

SPUN120308 TN5120

NameAnsi Identifying order number inch alternative

SPUN423 TN5120

RE Corner radius

0.8 mm

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

SPUN120308

STDDESAnsi Standard designation ANSI

SPUN423

TCINS Tolerance class insert

U - Not treated

Working process

DDA - External turning,DDI - Internal turning,F - Milling
