SNMT1205ZNEN-G ACP300

Артикул: SNMT1205ZNEN-G ACP300

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

AS Clearance angle wiper edge

0 Degree

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

F - Sharpedged

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

9/27/2011

DIN

SN1205ZN3N

EPSR Insert included angle

90 Degree

FamilyProducts

SNMT1205ZNEN-G

GRDMFG Grade manufacturers designation

ACP300

GRDPRIO Standard designation of the grade main application

HC-P30

IC Inscribed circle diameter

12.7 mm

ID Technical product number

SNMT1205ZNEN-G ACP300

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

12.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SN1205ZN3N

Name Identifying order number

SNMT1205ZNEN-G ACP300

S Insert thickness

5.6 mm

S1 Insert thickness total

5.6 mm

STDDES Standard designation

SNMT1205ZNEN-G

TCINS Tolerance class insert

Working process

No working processes available
