SNMN120408 TH10

Артикул: SNMN120408 TH10

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

0 - Without chip breaker

COMPC Company code

TT - Tungaloy

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

9/27/2012

DIN

SN1204 1N

EPSR Insert included angle

90 Degree

FamilyProducts

indexable insert, BX90S full CBN

GRDMFG Grade manufacturers designation

TH10

GRDPRIO Standard designation of the grade main application

HW-K10

IC Inscribed circle diameter

12.7 mm

IFS Insert mounting style code

1 - Without bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

12.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SN1204 1N

Name Identifying order number

SNMN120408 TH10

NameAnsi Identifying order number inch alternative

SNMN 432 TH10

RE Corner radius

0.8 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

SNMN120408

STDDESAnsi Standard designation ANSI

SNMN432

TCINS Tolerance class insert

Working process

DDA - External turning
