SNMG434 EGZ AC420K

Артикул: SNMG434 EGZ AC420K

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

COATN Coating / Покрытие

Super FF

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5.16 mm

Delivery state valid from

10/26/2011

DIN

SN1204 2N

EPSR Insert included angle

90 Degree

FamilyProducts

Sumitomo indexable insert for turning SNMG-NGZ

GRDMFG Grade manufacturers designation

AC420K

GRDPRIO Standard designation of the grade main application

HC-K20

IC Inscribed circle diameter

12.7 mm

ID Technical product number

SNMG434 EGZ AC420K

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

12.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SN1204 2N

Materials

Name Identifying order number

SNMG434 EGZ AC420K

RE Corner radius

1.6 mm

S Insert thickness

4.762 mm

S1 Insert thickness total

4.762 mm

STDDES Standard designation

SNMG120416

STDDESAnsi Standard designation ANSI

SNMG434

TCINS Tolerance class insert

Working process

No working processes available
