SNMG150608-TM T9015

Артикул: SNMG150608-TM T9015

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

COATN Coating / Покрытие

MT-CVD

COMPC Company code

TT - Tungaloy

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

6.35 mm

Delivery state valid from

8/1/2012

DIN

SN1506 2N

EPSR Insert included angle

90 Degree

FamilyProducts

negative insert w/ chipbreaker, medium operation

GRD2ND Standard designation of the grade 2nd application

HC-P20

GRDMFG Grade manufacturers designation

T9015

GRDPRIO Standard designation of the grade main application

HC-P10

IC Inscribed circle diameter

15.875 mm

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

15.875 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SN1506 2N

Materials

P,M

Name Identifying order number

SNMG150608-TM T9015

RE Corner radius

0.8 mm

STDDES Standard designation

SNMG150608

STDDESAnsi Standard designation ANSI

SNMG542

TCINS Tolerance class insert

Working process

DDA - External turning
