SEMT13T3AGSN-G DA2200

Артикул: SEMT13T3AGSN-G DA2200

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

20 Degree

AS Clearance angle wiper edge

30 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating / Покрытие

PKD

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

1/16/2007

DIN

SE13T3AG3N

EPSR Insert included angle

90 Degree

FamilyProducts

insert for milling

GRDMFG Grade manufacturers designation

DA2200

GRDPRIO Standard designation of the grade main application

IC Inscribed circle diameter

13.4 mm

ID Technical product number

SEMT13T3AGSN-G DA2200

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

KCH Corner chamfer angle

45 Degree

KRINS Cutting edge angle major

45 Degree

L Cutting edge length

13.4 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SE13T3AG3N

Name Identifying order number

SEMT13T3AGSN-G DA2200

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

STDDES Standard designation

SEMT13T3AGSN

TCINS Tolerance class insert

Working process

No working processes available
