Главная Каталог продукции Toolunited 16 201-02 - Square insert SDKR 1203AUTR-HS IC250

SDKR 1203AUTR-HS IC250

Артикул: 5600821

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

BS Wiper edge length

1.7 mm

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

T - Chamfered

COATN Coating / Покрытие

TiN

COMPC Company code

IS - Iscar

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

2/1/2012

DIN

SD1203 1R

EPSR Insert included angle

90 Degree

FamilyProducts

SDKR 1203AUTR-HS IC250

GRD2ND Standard designation of the grade 2nd application

HC-P35

GRD3RD Standard designation of the grade 3rd application

HC-M40

GRDMFG Grade manufacturers designation

IC250

GRDPRIO Standard designation of the grade main application

HC-P15

IC Inscribed circle diameter

6.5 mm

ID Technical product number

5600821

IFS Insert mounting style code

1 - Without bore

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

6.5 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SD1203 1R

Name Identifying order number

SDKR 1203AUTR-HS IC250

S Insert thickness

3.2 mm

S1 Insert thickness total

3.2 mm

TCINS Tolerance class insert

K - Cold formed

Working process

No working processes available
