SCMA120412 AC420K

Артикул: SCMA120412 AC420K

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CB Chip breaker face count

0 - Without chip breaker

COATN Coating / Покрытие

Super FF

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

10/26/2011

DIN

SC1204122N

EPSR Insert included angle

90 Degree

FamilyProducts

insert for turning SCMA

GRDMFG Grade manufacturers designation

AC420K

GRDPRIO Standard designation of the grade main application

HC-K20

IC Inscribed circle diameter

12.7 mm

ID Technical product number

SCMA120412 AC420K

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SC1204122N

Name Identifying order number

SCMA120412 AC420K

RE Corner radius

1.2 mm

S Insert thickness

4.762 mm

S1 Insert thickness total

4.762 mm

STDDES Standard designation

SCMA120412

STDDESAnsi Standard designation ANSI

SCMA433

TCINS Tolerance class insert

Working process

No working processes available
