SCMA09T308 AC420K

Артикул: SCMA09T308 AC420K

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CB Chip breaker face count

0 - Without chip breaker

COATN Coating / Покрытие

Super FF

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

Delivery state valid from

10/26/2011

DIN

SC09T3082N

EPSR Insert included angle

90 Degree

FamilyProducts

insert for turning SCMA

GRDMFG Grade manufacturers designation

AC420K

GRDPRIO Standard designation of the grade main application

HC-K20

IC Inscribed circle diameter

9.525 mm

ID Technical product number

SCMA09T308 AC420K

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SC09T3082N

Name Identifying order number

SCMA09T308 AC420K

RE Corner radius

0.8 mm

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

STDDES Standard designation

SCMA09T308

STDDESAnsi Standard designation ANSI

SCMA32.52

TCINS Tolerance class insert

Working process

No working processes available
