Артикул:
12212262444
В наличии
Характеристики
AN Clearance angle major
0 Degree
CB Chip breaker face count
2 - With chip breaker on both sides
CBMD Chip breaker manufacturers designation
SM
COMPC Company code
WI - Widia
CSP Coolant supply property
0 - Without coolant supply
D1 Fixing hole diameter
5.16 mm
Delivery state valid from
8.9 €
DIN
SN1204082N
EPSR Insert included angle
90 Degree
FamilyProducts
Insert
GRDMFG Grade manufacturers designation
TN8025
GRDPRIO Standard designation of the grade main application
HC-M25
ID Technical product number
12212262444
IFS Insert mounting style code
2 - With cylindrical bore
IH Insert hand
N - Neutral
Interface codes
J6 /
ISISO ISO property
0
ISYC Subclass
201-02 - Square insert
L Cutting edge length
12.7 mm
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
SN1204082N
Materials
M,S
Name Identifying order number
12212262444
RE Corner radius
0.8 mm
S Insert thickness
4.76 mm
S1 Insert thickness total
4.76 mm
STDDES Standard designation
SNMP120408
STDDESAnsi Standard designation ANSI
SNMP432
Working process
No working processes available
