12212183975
12212183975
Артикул:
12212183975
В наличии
Характеристики
AN Clearance angle major
0 Degree
CB Chip breaker face count
1 - With chip breaker one-side
CBMD Chip breaker manufacturers designation
SH
COMPC Company code
WI - Widia
CSP Coolant supply property
0 - Without coolant supply
D1 Fixing hole diameter
7.94 mm
Delivery state valid from
19.2 €
DIN
SN1906242N
EPSR Insert included angle
90 Degree
FamilyProducts
Insert
GRDMFG Grade manufacturers designation
TN7015
GRDPRIO Standard designation of the grade main application
HC-P15
ID Technical product number
12212183975
IFS Insert mounting style code
2 - With cylindrical bore
IH Insert hand
N - Neutral
Interface codes
J6 /
ISISO ISO property
0
ISYC Subclass
201-02 - Square insert
L Cutting edge length
19.05 mm
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
SN1906242N
Materials
P,M
Name Identifying order number
12212183975
RE Corner radius
2.4 mm
S Insert thickness
6.35 mm
S1 Insert thickness total
6.35 mm
STDDES Standard designation
SNMM190624
STDDESAnsi Standard designation ANSI
SNMM6--4--6-
Working process
No working processes available
