L1070510101TH35
L1070510101TH35
Артикул:
L1070510101TH35
В наличии
Характеристики
COMPC Company code
HORN - Paul Horn
Delivery state valid from
6/27/2017
DIN
HORN-10700
FamilyProducts
System Mini 107
GRDMFG Grade manufacturers designation
TH35
IC Inscribed circle diameter
5.2 mm
ID Technical product number
L1070510101TH35
IH Insert hand
L - Left
Interface codes
J6 /
ISYC Subclass
202-11 - Thread chaser
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HORN-10700
Name Identifying order number
L1070510101TH35
NOF Flute count
1
PDPT Profile depth insert
4 mm
PDX Profile distance X
2.8 mm
PFS Profile form
8
PNA Profile included angle
60 Degree
S1 Insert thickness total
5.2 mm
TPN Thread pitch minimum
1 mm
TPX Thread pitch maximum
1.25 mm
TTP Thread type
V
W1 Insert width
3.5 mm
Working process
DSA - External thread chasing
