Главная Каталог продукции Toolunited 15 201-09 - Octogonal insert OFEX05T305SN-BP R2624

OFEX05T305SN-BP R2624

Артикул: OFEX05T305SN-BP R2624

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

25 Degree

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating / Покрытие

TiAIN

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.6 mm

Delivery state valid from

051

DIN

OF05T3057N

EPSR Insert included angle

135 Degree

FamilyProducts

Octogonal insert

GRD2ND Standard designation of the grade 2nd application

HC-M25

GRDMFG Grade manufacturers designation

R2624

GRDPRIO Standard designation of the grade main application

HC-P25

IC Inscribed circle diameter

12.7 mm

ID Technical product number

OFEX05T305SN-BP R2624

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-09 - Octogonal insert

L Cutting edge length

5 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

OF05T3057N

Materials

P,M,K

Name Identifying order number

OFEX05T305SN-BP R2624

NOI Insert index count

RE Corner radius

0.5 mm

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

STDDES Standard designation

OFEX05T305SN

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

FEC - Square shoulder milling,FPL - Face milling
