Главная Каталог продукции Toolunited 15 201-09 - Octogonal insert OFEN070405SN R2624

OFEN070405SN R2624

Артикул: OFEN070405SN R2624

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

25 Degree

CB Chip breaker face count

0 - Without chip breaker

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating / Покрытие

TiAIN

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

051

DIN

OF0704 1N

EPSR Insert included angle

135 Degree

FamilyProducts

Octogonal insert

GRD2ND Standard designation of the grade 2nd application

HC-M25

GRDMFG Grade manufacturers designation

R2624

GRDPRIO Standard designation of the grade main application

HC-P25

IC Inscribed circle diameter

18.1 mm

ID Technical product number

OFEN070405SN R2624

IFS Insert mounting style code

1 - Without bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-09 - Octogonal insert

L Cutting edge length

7.4 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

OF0704 1N

Materials

P,M,K

Name Identifying order number

OFEN070405SN R2624

NOI Insert index count

RE Corner radius

0.5 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

OFEN070405SN

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

No working processes available
