OAKU 060508ER-F40 CTC5240

Артикул: 11486383

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

3 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

F40

CECC Cutting edge condition code

E - Rounded

COMPC Company code

CE - Ceratizit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5.8 mm

DIN

OA0605083R

EPSR Insert included angle

135 Degree

FamilyProducts

Wendeplatte System 273-06 OAKU-F40

GRDMFG Grade manufacturers designation

CTC5240

GRDPRIO Standard designation of the grade main application

HC-M40

IC Inscribed circle diameter

17.18 mm

ID Technical product number

11486383

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-09 - Octogonal insert

L Cutting edge length

6 mm

LE Cutting edge effective length

2 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

OA0605083R

Name Identifying order number

OAKU 060508ER-F40 CTC5240

RE Corner radius

0.8 mm

S Insert thickness

5.56 mm

S1 Insert thickness total

5.56 mm

STDDES Standard designation

OAKU060508ER

TCINS Tolerance class insert

K - Cold formed

Working process

FPL - Face milling
