LDLX150308 R R2624

Артикул: LDLX150308 R R2624

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

COATN Coating / Покрытие

TiAIN

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.5 mm

Delivery state valid from

051

DIN

LD1503 3R

EPSR Insert included angle

90 Degree

FamilyProducts

Rectangular insert

GRD2ND Standard designation of the grade 2nd application

HC-M25

GRDMFG Grade manufacturers designation

R2624

GRDPRIO Standard designation of the grade main application

HC-P25

IC Inscribed circle diameter

9.52 mm

ID Technical product number

LDLX150308 R R2624

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-04 - Rectangular insert

L Cutting edge length

15 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

LD1503 3R

Materials

P,M,K

Name Identifying order number

LDLX150308 R R2624

RE Corner radius

0.8 mm

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

LDLX150308R

TCINS Tolerance class insert

W1 Insert width

9.52 mm

Working process

FEC - Square shoulder milling,FPL - Face milling
