Главная Каталог продукции Toolunited 15 201-04 - Rectangular insert LDKT1504PDSR R635

LDKT1504PDSR R635

Артикул: LDKT1504PDSR R635

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CECC Cutting edge condition code

S - Chamfered and rounded

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.5 mm

Delivery state valid from

051

DIN

LD1504PD3R

EPSR Insert included angle

90 Degree

FamilyProducts

Rectangular insert

GRD2ND Standard designation of the grade 2nd application

HC-M30

GRDMFG Grade manufacturers designation

R635

GRDPRIO Standard designation of the grade main application

HC-P30

IC Inscribed circle diameter

9.52 mm

ID Technical product number

LDKT1504PDSR R635

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-04 - Rectangular insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

15.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

LD1504PD3R

Materials

P,M

Name Identifying order number

LDKT1504PDSR R635

RE Corner radius

0.8 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

LDKT1504PDSR

TCINS Tolerance class insert

K - Cold formed

W1 Insert width

9.52 mm

Working process

No working processes available
