Главная Каталог продукции Toolunited 15 201-04 - Rectangular insert H80 40000.012710

H80 40000.012710

Артикул: 1500038

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CBMD Chip breaker manufacturers designation

COMPC Company code

KOG - Komet Group

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

4/24/2012

DIN

LN1205103N

EPSR Insert included angle

90 Degree

FamilyProducts

LNHX 120510-01 BK2710

GRDMFG Grade manufacturers designation

BK2710

ID Technical product number

1500038

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-04 - Rectangular insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

LN1205103N

Name Identifying order number

H80 40000.012710

RE Corner radius

0 mm

S1 Insert thickness total

5.56 mm

STDDES Standard designation

LNHX120510

TCINS Tolerance class insert

Working process

No working processes available
