SPHX15T6PCERGNT1W KB1340

Артикул: 1833502

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

1/4/2011

DIN

KH-WP SPHX90 W1505

EPSR Insert included angle

90 Degree

FamilyProducts

FIX-PERFECT INSERT MILLING 1C

GRD2ND Standard designation of the grade 2nd application

BN-K30

GRDMFG Grade manufacturers designation

KB1340

GRDPRIO Standard designation of the grade main application

BN-K10

ID Technical product number

1833502

IFS Insert mounting style code

4 - Counter bore for screws with taper angle from 70° to 90°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

14 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

KH-WP SPHX90 W1505

Name Identifying order number

SPHX15T6PCERGNT1W KB1340

S Insert thickness

6.6 mm

S1 Insert thickness total

6.6 mm

STDDES Standard designation

SPHX15T6PCER

TCINS Tolerance class insert

Working process

No working processes available
