Главная Каталог продукции Toolunited 15 201-02 - Square insert 214777 GG

214777 GG

Артикул: 214777 GG

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

COMPC Company code

HOG - Hoffmann Group

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

1/11/2017

DIN

SP1205PC3R

EPSR Insert included angle

90 Degree

FamilyProducts

Wiper edge insert, one cutting edge HB 7710 GG GAR

GRDMFG Grade manufacturers designation

HB7710

IC Inscribed circle diameter

11.35 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

11.35 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SP1205PC3R

Name Identifying order number

214777 GG

RE Corner radius

0.8 mm

S Insert thickness

5.5 mm

STDDES Standard designation

SPHX1205PC

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

No working processes available

WT Weight of item

0.018 kg
