W27 20100.0404 P40
W27 20100.0404 P40
Артикул:
1475811
В наличии
Характеристики
COMPC Company code
KOG - Komet Group
CSP Coolant supply property
0 - Without coolant supply
Delivery state valid from
10/22/2014
DIN
66627
EPSR Insert included angle
95 Degree
FamilyProducts
W27 20100.0404 P40
GRDMFG Grade manufacturers designation
P40
GRDPRIO Standard designation of the grade main application
HW-P40
IC Inscribed circle diameter
3 mm
ID Technical product number
1475811
IH Insert hand
N - Neutral
Interface codes
J6 /
ISISO ISO property
0
ISYC Subclass
201-00 - Regular Insert unspecified
L Cutting edge length
4.31 mm
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
66627
Name Identifying order number
W27 20100.0404 P40
RE Corner radius
0.4 mm
Working process
No working processes available
Главный задний угол (AN) / Clearance angle major (AN)
8 Degree
