H60 44100.84
H60 44100.84
Артикул:
1496517
В наличии
Характеристики
COMPC Company code
KOG - Komet Group
CSP Coolant supply property
0 - Without coolant supply
Delivery state valid from
4/24/2012
DIN
78221
FamilyProducts
XOHX 2205-44,1 BK84
GRDMFG Grade manufacturers designation
BK84
IC Inscribed circle diameter
5.3 mm
ID Technical product number
1496517
IFS Insert mounting style code
3 - Counter bore for screws with taper angle from 40° to 60°
IH Insert hand
N - Neutral
Interface codes
J6 /
ISISO ISO property
0
ISYC Subclass
201-00 - Regular Insert unspecified
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
78221
Name Identifying order number
H60 44100.84
RE Corner radius
0 mm
S1 Insert thickness total
5.56 mm
STDDES Standard designation
XOHX2205
TCINS Tolerance class insert
H
Working process
No working processes available
