Главная Каталог продукции Toolunited 15 201-05 - Parallelogram-shaped insert XCET 040102FL-27Q H210T

XCET 040102FL-27Q H210T

Артикул: XCET 040102FL-27Q H210T

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

ANN Clearance angle minor

7 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

27Q

CECC Cutting edge condition code

F - Sharpedged

COMPC Company code

CE - Ceratizit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

2.1 mm

DIN

XC0401023L

EPSR Insert included angle

88 Degree

FamilyProducts

turning insert

GRD2ND Standard designation of the grade 2nd application

HW-N10

GRD3RD Standard designation of the grade 3rd application

HW-S10

GRDMFG Grade manufacturers designation

H210T

GRDPRIO Standard designation of the grade main application

HW-K10

IC Inscribed circle diameter

4.5 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

L - Left

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

6.5 mm

LE Cutting edge effective length

4 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

XC0401023L

Name Identifying order number

XCET 040102FL-27Q H210T

RE Corner radius

0.2 mm

S Insert thickness

1.8 mm

S1 Insert thickness total

1.8 mm

STDDES Standard designation

XCET040102FL

TCINS Tolerance class insert

W1 Insert width

4.5 mm

Working process

No working processes available
