Главная Каталог продукции Toolunited 15 201-05 - Parallelogram-shaped insert KEGT25L531PEERLDJ KC410M

KEGT25L531PEERLDJ KC410M

Артикул: 2526351

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

20 Degree

ANN Clearance angle minor

15 Degree

AS Clearance angle wiper edge

20 Degree

BS Wiper edge length

3.06 mm

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

LDJ

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

TiB2

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

9/27/2015

DIN

KE25L5PE3R

EPSR Insert included angle

55 Degree

FamilyProducts

Indexable Insert KE...25L5

GAN Insert rake angle

15 Degree

GRDMFG Grade manufacturers designation

KC410M

GRDPRIO Standard designation of the grade main application

H W

ID Technical product number

2526351

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

31.47 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

KE25L5PE3R

Name Identifying order number

KEGT25L531PEERLDJ KC410M

NameAnsi Identifying order number inch alternative

KG2531ELDJ KC410M

NOI Insert index count

RE Corner radius

3.1 mm

S Insert thickness

5.21 mm

S1 Insert thickness total

5.21 mm

STDDES Standard designation

KEGT25L531PEERLDJ

TCINS Tolerance class insert

W1 Insert width

14.6 mm

Working process

FEC - Square shoulder milling,FNU - Groove milling
