Главная Каталог продукции Toolunited 15 201-05 - Parallelogram-shaped insert EDCT10T331PDFRLDJ K313

EDCT10T331PDFRLDJ K313

Артикул: 3684823

В наличии

В корзину

Описание

Характеристики

ANN Clearance angle minor

15 Degree

AS Clearance angle wiper edge

15 Degree

BN Face land width

0.05 mm

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

LDJ

CECC Cutting edge condition code

F - Sharpedged

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

1/4/2011

DIN

ED10T3PD3R

EPSR Insert included angle

75 Degree

FamilyProducts

LDJ (Periphery Ground & Polished) 15° Rake Angle

GRD2ND Standard designation of the grade 2nd application

HW-S20

GRD3RD Standard designation of the grade 3rd application

HW-S10

GRDMFG Grade manufacturers designation

K313

GRDPRIO Standard designation of the grade main application

HW-K15

ID Technical product number

3684823

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

11.52 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

ED10T3PD3R

Name Identifying order number

EDCT10T331PDFRLDJ K313

RE Corner radius

3.1 mm

S Insert thickness

3.75 mm

S1 Insert thickness total

3.75 mm

STDDES Standard designation

EDCT10T331PDFRLDJ

STDDESAnsi Standard designation ANSI

EC1031FLDJ

W1 Insert width

6.71 mm

Working process

FEC - Square shoulder milling

Главный задний угол (AN) / Clearance angle major (AN)

15 Degree
