Главная Каталог продукции Toolunited 15 201-05 - Parallelogram-shaped insert EDCT10T304PDFRLDJ K313

EDCT10T304PDFRLDJ K313

Артикул: 3682449

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

ANN Clearance angle minor

15 Degree

AS Clearance angle wiper edge

15 Degree

BN Face land width

0.05 mm

BS Wiper edge length

1.98 mm

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

LDJ

CECC Cutting edge condition code

F - Sharpedged

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

1/4/2011

DIN

ED10T3PD3R

EPSR Insert included angle

75 Degree

FamilyProducts

LDJ (Periphery Ground & Polished) 15° Rake Angle

GRD2ND Standard designation of the grade 2nd application

HW-S20

GRD3RD Standard designation of the grade 3rd application

HW-S10

GRDMFG Grade manufacturers designation

K313

GRDPRIO Standard designation of the grade main application

HW-K15

ID Technical product number

3682449

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

12.05 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

ED10T3PD3R

Name Identifying order number

EDCT10T304PDFRLDJ K313

RE Corner radius

0.4 mm

S Insert thickness

3.75 mm

S1 Insert thickness total

3.75 mm

STDDES Standard designation

EDCT10T304PDFRLDJ

STDDESAnsi Standard designation ANSI

EC1004FLDJ

W1 Insert width

6.75 mm

Working process

FEC - Square shoulder milling
