Главная Каталог продукции Toolunited 15 201-05 - Parallelogram-shaped insert APHT1604PDFR-ALC LC610T

APHT1604PDFR-ALC LC610T

Артикул: 6401073

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

AS Clearance angle wiper edge

15 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

ALC

CECC Cutting edge condition code

F - Sharpedged

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.5 mm

Delivery state valid from

1/9/2013

DIN

AP1604PD3R

EPSR Insert included angle

85 Degree

FamilyProducts

85° Rhomboidic insert

GRDMFG Grade manufacturers designation

LC610T

GRDPRIO Standard designation of the grade main application

HC-K10

IC Inscribed circle diameter

9.52 mm

ID Technical product number

6401073

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

17.3 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

AP1604PD3R

Materials

Name Identifying order number

APHT1604PDFR-ALC LC610T

NOI Insert index count

RE Corner radius

0.8 mm

S Insert thickness

5.26 mm

S1 Insert thickness total

5.26 mm

STDDES Standard designation

APHT1604PDFR

TCE Tipped cutting edge code

TCINS Tolerance class insert

W1 Insert width

9.52 mm

Working process

FEC - Square shoulder milling,FFO - Die milling,FNU - Groove milling,FPL - Face milling
