ADKT1505PDSR-BP LW225

ADKT1505PDSR-BP LW225

ADKT1505PDSR-BP LW225

Boehlerit
Артикул: ADKT1505PDSR-BP LW225
В наличии
В корзину
Описание
Характеристики
AN Clearance angle major
15 Degree
AS Clearance angle wiper edge
15 Degree
CB Chip breaker face count
1 - With chip breaker one-side
CBMD Chip breaker manufacturers designation
BP
CECC Cutting edge condition code
S - Chamfered and rounded
COMPC Company code
BK - Boehlerit
CSP Coolant supply property
0 - Without coolant supply
D1 Fixing hole diameter
4.5 mm
Delivery state valid from
8.648 €
DIN
AD1505PD3R
EPSR Insert included angle
85 Degree
FamilyProducts
85° Rhomboidic insert
GRDMFG Grade manufacturers designation
LW225
GRDPRIO Standard designation of the grade main application
HW-P25
IC Inscribed circle diameter
9.58 mm
ID Technical product number
ADKT1505PDSR-BP LW225
IFS Insert mounting style code
3 - Counter bore for screws with taper angle from 40° to 60°
IH Insert hand
R - Right
Interface codes
J6 /
ISISO ISO property
0
ISYC Subclass
201-05 - Parallelogram-shaped insert
KRINS Cutting edge angle major
90 Degree
L Cutting edge length
15.68 mm
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
AD1505PD3R
Materials
P
Name Identifying order number
ADKT1505PDSR-BP LW225
RE Corner radius
0.8 mm
S Insert thickness
5.65 mm
S1 Insert thickness total
5.65 mm
STDDES Standard designation
ADKT1505PDSR
TCINS Tolerance class insert
K - Cold formed
W1 Insert width
9.58 mm
Working process
No working processes available
