Главная Каталог продукции Toolunited 15 201-05 - Parallelogram-shaped insert ADKT0903PESR-BP R635

ADKT0903PESR-BP R635

Артикул: ADKT0903PESR-BP R635

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

AS Clearance angle wiper edge

20 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

S - Chamfered and rounded

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

2.8 mm

Delivery state valid from

050

DIN

AD0903PE3R

EPSR Insert included angle

85 Degree

FamilyProducts

85° Rhomboidic insert

GRD2ND Standard designation of the grade 2nd application

HC-M30

GRDMFG Grade manufacturers designation

R635

GRDPRIO Standard designation of the grade main application

HC-P30

IC Inscribed circle diameter

6.35 mm

ID Technical product number

ADKT0903PESR-BP R635

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

9.52 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

AD0903PE3R

Materials

P,M

Name Identifying order number

ADKT0903PESR-BP R635

RE Corner radius

0.4 mm

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

ADKT0903PESR

TCINS Tolerance class insert

K - Cold formed

W1 Insert width

6.35 mm

Working process

No working processes available
