Главная Каталог продукции Toolunited 15 201-05 - Parallelogram-shaped insert ADHT12T306SR R635

ADHT12T306SR R635

Артикул: ADHT12T306SR R635

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CECC Cutting edge condition code

S - Chamfered and rounded

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4 mm

Delivery state valid from

050

DIN

AD12T3 3R

EPSR Insert included angle

85 Degree

FamilyProducts

85° Rhomboidic insert

GRD2ND Standard designation of the grade 2nd application

HC-M30

GRDMFG Grade manufacturers designation

R635

GRDPRIO Standard designation of the grade main application

HC-P30

IC Inscribed circle diameter

9.52 mm

ID Technical product number

ADHT12T306SR R635

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

L Cutting edge length

12.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

AD12T3 3R

Materials

P,M

Name Identifying order number

ADHT12T306SR R635

RE Corner radius

0.6 mm

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

STDDES Standard designation

ADHT12T306SR

TCINS Tolerance class insert

W1 Insert width

9.52 mm

Working process

No working processes available
